5 Connecting the VS-88HDCPxl
Always switch off the power to each device before connecting it to your
VS-88HDCPxl. After connecting your VS-88HDCPxl, connect its
power and then switch on the power to each device.
To connect the VS-88HDCPxl as illustrated in the example in Figure 3:
1. Connect up to eight DVI sources (for example, DVD players) to the IN DVI
connectors.
2. Connect the OUT DVI connectors to up to eight DVI acceptors (for example,
DVI displays).
3. If required, connect a PC and/or controller to the RS-232 port (see
Section 5.1) and/or the Ethernet port (see Section 5.2).
4. Connect the device to the mains electricity (not shown in Figure 3).
5. Power the device.
6. If required, acquire the EDID (see Section 6.5).
