ClimTec
®
Table for ballast weight requirements when using the tower without outriggers, number of
weights Art.-No. 704306
m
A
A
A
A
Position A Total Position A Total
3.00 0 0 0 0
5.00 3 12 3 12
7.00 7 28 6 24
Table for ballast weight requirements when using the tower with outriggers, number of
weights Art.-No. 704306
m
A A
AA
Position A Total Position A Total
5.00 0 0 0 0
7.00 1 4 0 0
