66
ClimTec
®
5. Disassembling ClimTec
®
ClimTec
®
has to be disassembled in reverse order of assembly.
6. Technical data
Article numbers and components’ weight
Art.-No. Name
Weight
approx.
715067 Base frame 5.60 kg
714008 Adjustable stabiliser 1.20 kg
715012 Vertical frame 2.0 m 4.20 kg
715029 Vertical frame 1.0 m 2.20 kg
712806 Horizontal brace, approx. 1.59 m 0.80 kg
712707 Diagonal brace, approx. 1.89 m 1.00 kg
710673 GuardMatic-System
®
3.20 kg
711007 Platform 9.40 kg
713001 Front/back board 1.60 kg
713506 Side board 0.60 kg
714305 Stabilisers 1.60 kg
718860 Locking bolts M5 x 65 mm 0.05 kg
718877 Locking bolts M5 x 85 mm 0.06 kg
718891 Set of screws, 3-part, hexagon screw M8 x 50 0.03 kg
714411 Locking pin 0.06 kg
Accesories
714107 Castor Ø 125 mm 1.40 kg
714169 Set of 4 castors Ø 125 mm and 4 locking pins 6.00 kg
914118 Castor Ø 150 mm, 115 mm height adjustable 3.90 kg
914323 Set of 4 castors Ø 150 mm, 115 mm height adjustable 15.30 kg
704306 Ballast weight 10.0 kg
714039 Outrigger 3.2 kg
7. Inspection, spare parts
All of the tower‘s parts must be checked for damage before erecting it and any damaged parts must be replaced.
The inspection must ensure that
– Weld seams and none of the components have any cracks.
– The components are not deformed or dented.
– The castors and hatches on the platforms are in proper working order.
Only ever use original KRAUSE components and spare parts.
