Kreg Straight Edge Guide User Manual

3
Pre-Assembly
Review this section before you begin. Ensure you have all tools and materials on
hand. Compare the package with the items listed in the Hardware Included and
Product Description sections. Ensure you have a clean, at area for joining the guide
rails. If any item appears missing or lost, do not use this product. Contact Technical
Support or return product to place of purchase.
Recommended Tools/Materials (Not Included)
#3 Phillips Screwdriver Straight Edge or Level Pencil
Hardware/Tools Included
A
E
G
D
I
F
B
C
H
DD
BB
CC FF
EE
AA
Straight Edge Guide Straight Edge Guide Extension Straight Edge Guide XL
AA - Set screws x 8 AA - Set screws x 8 AA - Set screws x 24
BB - Cutline indicator stop
thumb screws x 2
n/a
BB - Cutline indicator stop
thumb screws x 2
CC - Cutline indicator stop
nuts x 2
n/a
CC - Cutline indicator stop
nuts x 2
DD - Hex wrench x 1 n/a DD - Hex wrench x 1
EE - Handle bolt x 1 n/a EE - Handle bolt x 1
FF - Handle nut x 1 n/a FF - Handle nut x 1
