Krell Industries KCT - Figure 1 the KCT Front Panel

Figure 1 The KCT Front Panel
Power 1 Power Button 2 Stand-by LED 3 Power LED Remote Control Functions 4 Infrared Sensor 5 Infrared Transmitter LED 1
Preamplifier Functions
6 Input Select Buttons 7 Tape Button 8 Mute Button 9 Phase Button
10 Zone Button 11 Main Zone LED 12 Zone 2 LED
Display 13 Front Panel Display Level Control 14 Level Control Knob Menu Functions 15 Menu Button 16 Enter Button
69 13 14
1
4 527
3
10
11
12
16
15
8
KCT
CLASS A
