Krell Industries KCT - Figure 2 the KCT Back Panel

Figure 2 The KCT Back Panel
Inputs 17 B-1 and B-2 Left and Right
Balanced Inputs
18 S-1, S-2, and S-3 Left and
Right Single-ended Inputs
19 Tape Left and Right Inputs 20 C-1 and C-2 Left and Right
CAST Inputs
Tape Output 21 Tape Output Main (Zone) Outputs 22 Preamp Left and Right Outputs 23 CAST Preamp Outputs Zone 2 Outputs 24 Balanced Left and Right Outputs 25 Single-ended Left and Right
Outputs
Back Panel Remote Control Inputs and Outputs 26 Krell Link In and Out 27 12 VDC In and Out 28 RC-5 In 29 RS-232 Phono Stage Connector 30 Phono Power Power 31 IEC Power Connector
17 20 21 22 23 26 28 271918
30
29 31
24
25
