KROHNE DK32 - Marking

2 DEVICE DESCRIPTION
8
VA FLOWMETERS
www.krohne.com 09/2022 - 4000419908 - AD VA Mech Ex Gb-Db R08 en
2.3 Marking
The flowmeters are identified by the following nameplates (examples are not to scale):
Nameplate DK32, DK34, DK32 .. HT, DK34 .. HT
Figure 2-8: Example of a nameplate for DK32 HT (ATEX)
Nameplate DK32, DK34, DK32 .. HT, DK34 .. HT
Figure 2-9: Example of a nameplate for DK32 HT (UKCA)
DK32 ... HT
P/A: 123456789.001
S/N: D################
TS: 200°C
PS: ... bar Ptmax: ... bar
PED/G1/4.3/SEP
Luft / air
0.0181 mPa s
1.013 bar abs.
1.293 kg/Nm3
20°CTag-No: ###################
Reg.No.PTB03ATEXD127X
II2G Ex h IIC T6...T3 Gb
II2D Ex h IIIC T200°C Db
Tamb -25°C ... +200°C
IP: 66/68
MD: 20##
PESR/G1/8/SEP
