27
2.10 OPTIMASS 9000 / 9010C
The OPTIMASS 9000 / 9010C is suitable for temperature classes T4….T1 according to the
following tables:
The cable supplied by KROHNE is designed for a continuous working temperature of up to
105°C. Alternative cabling must be a heat-resistant type with a continuous working tempera-
ture of 80°C.
2.11 OPTIGAS 5000 / 5010C / 5300C
The OPTIGAS 5000 / 5010C / 5300C is suitable for temperature classes T4….T1 according to the
following tables:
OPTIGAS 5300C with stainless steel converter housing and without
heating jacket / insulation
Ambient Temp.
Tamb °C
Max. medium temp
TM °C
Temperature Class
40
40 T4
93 T3 – T1
50 70 T3 – T1
55 55 T3 – T1
OPTIGAS 5300C with aluminium converter housing and without heating
jacket / insulation
Ambient Temp.
Tamb °C
Max. medium
temp. TM °C
Temperature Class
40
40 T4
93 T3 – T1
50 93 T3 – T1
60 60 T3 – T1
65* 65 T4 - T1
OPTIGAS 5000 / 5010C without heating jacket / insulation
Ambient Temp.
Tamb °C
Max. medium
temp. TM °C
Temperature Class
65
70 T4
80 T4
95 T3 – T1
OPTIMASS 9000 / 9010C with heating jacket / insulation
Ambient Temp.
Tamb °C
Max. medium
temp.TM °C
Temperature Class
Max. Surface
Temp. °C
65
95 T4 T130
160 T3 T195
255 T2 T290
350 T1 T385
* Only for equipment configurations according to the table in section 2.2
The cable supplied by KROHNE is designed for a continuous working temperature of up to
105°C. Alternative cabling must be a heat-resistant type with a minimum continuous working
temperature of 80°C.
AD OPTIMASS 300_010 Haz Areas Rev 01.qxp 05/03/2014 13:25 Page 27
