33
RReeff DDiissppllaayy DDeessccrriippttiioonn && SSeettttiinnggss
CC66 DDeevviiccee ccttdd......
C6.6 Special Functions
C6.6.1 Reset Errors
This menu function can be used to reset all errors, that are not
removed automatically (e.g. power fail)
step 1:
Reset? no: exit the function
yes: resets the errors and exits the function.
C6.6.2 Save Settings
In this menu all settings can be saved in different storage places)
Step 1
Save Settings?
break Exit the menu without saving
backup 1 Saves the settings in the backup 1 stor-
age place
backup 2 Saves the settings in the backup 2 stor-
age place
Step 2
Go on with copy? (Note: There is no possibility to
undo this command!)
NNoo
Exit function without saving
YYeess
Copy the actual settings to the selected stor-
age place and exits the function.
Note: PROFIBUS interface settings will not be saved
C6.6.3 Load Settings
(in this menu all settings can be loaded from different storage places,
where settings have been saved before)
step 1
Load Settings?
break Exits the menu without loading
factory settings Loads the settings from the deliv-
ery
backup 1 Loads the settings from the back-
up 1 storage place)
backup 2 Loads the settings from the back-
up 2 storage place)
step 2
go on with copy? (Note: There is no possibility to
undo this command!)
NNoo
exit function without saving
YYeess
copy the actual settings to the selected stor-
age place and exits the function
Note: PROFIBUS interface settings will not be loaded
C6.8 Physical Block This menu is only available, if a PROFIBUS interface is present
C6.8.1 Station Address
Selects the PROFIBUS station address of the device
NNoottee::
The PROFIBUS address can also be changed using the PROFIBUS
service “set_slave_add”. The input range is 0...125 according to the
PROFIBUS specification. Address 126 is the default address and can-
not be set via the PROFIBUS service “set_slave_add” - use menu
instead to reset to default address.
