34
RReeff DDiissppllaayy DDeessccrriippttiioonn && SSeettttiinnggss
CC66 DDeevviiccee ccttdd......
C6.8.2 Information
Gives information about the hardware version, software version and
the calibration/test date of this interface
C6.8.3 Diag. extension
Gives a representation of the status information, that is also avail-
able on the PROFIBUS interface. The status is displayed in hexa-
decimal format.
C6.8.4 Diag. extension 2
C6.8.5
Diag. extension i.
(intern)
C6.9 quick setup
In this menu some settings in the Quick Setup can be activated. In the default configuration the settings in
the Quick Setup are activated.
C6.9.1 reset totaliser 1
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeess
quick access activated
NNoo
quick access not activated
C6.9.2 reset totaliser 2
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeess
quick access activated
NNoo
quick access not activated
C6.9.3 reset totaliser 3
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeess
quick access activated
NNoo
quick access not activated
DD SSeerrvviiccee
This menu is protected. You will need to use the service password to gain access.
D2 System
In this menu all functions related to different data sets can be
found.
D2.2 Service Parameters
D2.2.1 Cold start
Resetting of the MFC300 can be done here but all changes up to
this point are automatically stored and cannot be discarded.
step 1 reset?
NNoo
terminates the function
yyeess
performs the reset and leaves the pro-
gramming mode
D2.2.2 Save Factory Data
Copies the actual data into the factory setting, this overwrites the
factory settings done during calibration)
Step 1
Save Settings?
break exits the menu without saving
factory settings saves the settings as factory
settings
Step 2
go on with copy? (there is no possibility to undo
this command)
NNoo
exit menu without saving
YYeess
copy the actual settings to the selected
storage place.
