MPT 700
5
1.1 Version and model
• MPT 700 with two burner groups per unit:
- current version: Type 2 / program version 6.0
- 8 modes of operation
- two parameter sets, switchable
- two mA inputs
- one three-point step input for multiplex operation
The MPT 700 can be adjusted to behave in the same way as a single-group unit
by setting the number of outputs for group 1 to 8 burners (parameter 15) and for
group 2 to 0 burners (parameter 16) and the setting indicator to group 1
(parameter 14).
To check the version, proceed as follows (see also section 2):
• Set the parameter number to 0 using the right section of the keypad.
• Press the top button on the right (+) for 5 sec.
⇒ the type and the program version number will then appear on the display.
Example:
display: 02.60 ⇒ Type 2 / program version 6.0
MPT 700:
• new model with switched +Vcc (+12...24VDC) and common ground (GND)
