Comprima V 150/Comprima V 180
Pos: 77 /BA/Wart ung/Rundball enpresse/Hydrauli k/Hydrauliksch altpläne/H ydraulikschaltpl an_Legenden_Co mprima V RP0 25_ohne XC @ 5 00\mod_14 94840120364 _78.docx @ 344 6551 @ @ 1
1
Standard equipment
3
"Hydraulic support jack" version
2
"Electronic baling pressure
adjustment" version
4
"Reversing device" version
Meaning of the valves in the hydraulic diagram
Q30
Baling pressure
Meaning of the icons in the hydraulic diagram
Tailgate at the bale chamber
Electronic baling pressure adjustment
Pick-up
Hydraulic support jack
Reversing device
