Before the Start of the New Season
86
Pos: 141.12 /Übers chriften/Übersc hriften 2/P-T /RReibkupplu ng @ 3\mod_1 20478245180 8_78.docx @ 72 905 @ 2 @ 1
16.3 Friction Clutch
Pos: 141.13 /BA /Sicherheit/Reib kupplung/Ac htung - Manip ulation an der Rei bkupplung @ 3 \mod_1204732 138258_78.doc x @ 72825 @ @ 1
Caution! - Manipulation of the friction clutch
Effect: Serious damage to the machine
• Manipulation of the overload protection changes the slip torque. This will lead to a loss of
warranty claims! Original KRONE spare parts only may be used.
Pos: 141.14 /BA /Einlagerung/Reib kupplung/Rei bkupplung entlüf ten @ 3\ mod_1204732297 351_78.doc x @ 72885 @ @ 1
Fig.
The friction clutch protects the tractor and the machine against damage. It is designed with a
permanently adjusted turning torque MR. The torque is applied on the housing of the friction
clutch (2).
Venting the friction clutch
Tighten the four nuts (1). Block the machine and move the friction clutch manually to the point
where it slips through. Loosen the nuts again.
Pos: 141.15 /BA /Inbetriebnah me/EasyCut/Hinw eis Reibkupplung @ 11\ mod_1223358975 938_78.docx @ 1 45593 @ @ 1
Note - Friction Clutch
Effect: Conserve functionality and increased service life
• The friction clutch (2) must be vented prior to commissioning and once a year prior to
harvesting. (See section Before the Start of the New Season "Friction clutch")
