Settings 10
Setting the cutting height 10.1
EasyCut F 320 M
Original Operating Instructions 150000808_01_en 53
10 Settings
WARNING
Risk of injury due to non-observance of relevant safety instructions
If the relevant safety instructions are not observed, persons may be seriously injured or killed.
To avoid accidents, the relevant safety instructions must be read and observed, refer to
page13.
WARNING
Risk of injury due to non-observance of safety instructions
If the relevant safety routines are not observed, persons may be seriously injured or killed.
The safety routines must be read and observed to avoid accidents, refer to page24.
10.1 Setting the cutting height
KMG000-035
The cutting height is adjusted via the top link(1).
Setting range of cutting height, .
ü The machine is in the working position, refer to page48.
Shut down and safeguard the machine, refer to page24.
Turn the top link until the cutting height is set.
ð Top link longer = smaller cutting height
ð Top link shorter = greater cutting height
For version with “high-cut skids”
The cutting height can be increased by means of high-cut skids.
