Introduction
10
Pos: 8.13 /BA/Einl eitung/Technis cheD aten/Sch wader/Straße nfahrt: geschwenkt eKr eiselar me4 Meter nicht überschreiten @ 7 6\mod_131 0015862571_78 .doc @ 666075
Road travel is only permitted with the swivelled rotary arms in transport position.
The max. height of 4 m must not be exceeded.
Pos: 8.14 /Abkürzu ngen /Abkürzu ngen sprach neutral/Schwader/ Swadro 807 @ 7 8\mod_131 3746086911_0. doc @ 693653
Swadro 807
Pos: 8.15 /BA/Einl eitung/Technis cheD aten/Sch wader/Swadro 8 07 @ 78\mod_ 13137408018 61_78.doc @ 69 3625
Type Swadro 807
Understeering coupling Piece standard
Number of rotors Piece 2
Number of arms / rotors Piece 10/13
Number of double tines / arm Piece 4
Working width of side swath approx. mm 6200
Rotor diameter approx. mm 2960
Height with tine arms/transport position approx. mm 3900
1)
Height of tine arms folded in /transport position approx. mm 3500
2)
Height in working position approx. mm 2200
Length approx. mm 7370
Width in transport position approx. mm 2995
Width in working position approx. mm 6200
Power consumption approx. kW/HP 37/50
PTO speed rpm max. 540
Equivalent continuous sound pressure level less than 70 d B(A)
Side swath acreage approx./h 6
Tyres for rotor running gear 16x6.50-8 4PR
Tyres for main running gear 4PR10.0/75-15.3 8PR
Lighting voltage Volts 12
Max. operating pressure of hydraulic system bar 200
Required hydraulic connections 1x single-action*
Max. permissible transport speed 40 km/h
Dead weight kg 1750
Permissible axle load kg 1000
Permissible supporting load kg 750
Pos: 8.16 /BA/Einl eitung/Technis cheD aten/Sch wader/1) Ausfü hrung: Zinken arm starr @ 77\ mod_13100385 73771_78.doc @ 6 66759
1) Design: Tine arm rigid
Pos: 8.17 /BA/Einl eitung/Technis cheD aten/Sch wader/2) Ausfü hrung: Zinken arm klappbar @ 7 7\mod_131003 8658714_78.doc @ 666786
2) Design: Tine arm folding
Pos: 8.18 /Abkürzu ngen /Abkürzu ngen Beschr eibung/*) EW= Ein fachwirkendes S teuergerät @ 76\mod_13099 63843144_78. doc@ 66601 1
*) SA= Single-action control unit
