Introduction
11
Pos: 8.20 /BA/Einl eitung/Technis cheD aten/Sch wader/Straße nfahrt: geschwenkt eKr eiselar me4 Meter nicht überschreiten @ 7 6\mod_131 0015862571_78 .doc @ 666075
Road travel is only permitted with the swivelled rotary arms in transport position.
The max. height of 4 m must not be exceeded.
Pos: 8.21 /Abkürzu ngen /Abkürzu ngen sprach neutral/Schwader/ Swadro 809 / S wadro 810 @ 78\mod_1313 746213644_0.d oc @ 693681
Swadro 809 / Swadro 810
Pos: 8.22 /BA/Einl eitung/Technis cheD aten/Sch wader/Swadro 8 09/810 @ 75\m od_130951533 0532_78.doc @ 663743
Type Swadro809 Swadro810
Understeering coupling Piece standard
Number of rotors Piece 2
Number of arms / rotors Piece 13 13
Number of double tines / arm Piece 4
Working width of side swath approx. mm 6750 6750
two swaths approx. mm - 2 x 3700
Rotor diameter approx. mm 3300 3300
Height with tine arms/transport position approx. mm 4170 4170
Height of tine arms folded in /transport
position
approx. mm 3720 3720
Height in working position approx. mm 2200
Length approx. mm 7770 7770
Width in transport position approx. mm 2995
Width in working position approx. mm 6750 7850
Power consumption approx. kW/HP 37/50
PTO speed rpm max. 540
Equivalent continuous sound pressure level less than 70 d B(A)
Side swath acreage approx./h 6,5 6,5
Acreage of two swaths approx./h - 7,5
Tyres for rotor running gear 16x6.50-8 4PR
Tyres for main running gear 4PR10.0/75-15.3 8PR
Lighting voltage Volts 12
Max. operating pressure of hydraulic
system
bar 200
Required hydraulic connections 1x single-
action*
1x single-
action*
1x double-
action**
Max. permissible transport speed 40 km/h
Dead weight kg 1980 1980
Permissible axle load kg 1150 1150
Permissible supporting load kg 830 830
Pos: 8.23 /Abkürzu ngen /Abkürzu ngen Beschr eibung/*) EW= Ein fachwirkendes S teuergerät @ 76\mod_13099 63843144_78. doc@ 66601 1
*) SA= Single-action control unit
Pos: 8.24 /Abkürzu ngen /Abkürzu ngen Beschr eibung/**) DW= D oppelwirkend es Steuergerät @ 7 6\mod_130 9963889815_78.d oc @ 666039
**) DA= Double-action control unit
