Introduction
12
Pos: 8.26 /Abkürzu ngen /Abkürzu ngen sprach neutral/Schwader/ Swadro 907 @ 1 \mod_1202 226168013_0.d oc@ 58250
Swadro 907
Pos: 8.27 /BA/Einl eitung/Technis cheD aten/Sch wader/Swadro 9 07 @ 75\mod_ 13094167570 03_78.doc @ 66 2846
Road travel is only permitted with the rotor arm swivelled out in transport position. The max.
height of 4 m must not be exceeded.
Type Swadro 907
Understeering coupling Piece standard
Number of rotors Piece 2
Number of arms / rotors Piece 15
Number of double tines / arm Piece 2
Working width of side swath approx. mm 8000
Rotor diameter approx. mm 3800
Height with tine arms/transport position approx. mm 4400
Height of tine arms folded in /transport position approx. mm 3900
Height in working position approx. mm 2200
Length approx. mm 9800
Width in transport position approx. mm 2995
Width in working position approx. mm 8000
Power consumption approx. kW/HP 51/70
PTO speed rpm max. 540
Equivalent continuous sound pressure level less than 70 d B(A)
Side swath acreage approx./h 8-9
Tyres for rotor running gear 16x6.50-8 4PR
Tyres for main running gear 15/55-17 10PR
Lighting voltage Volts 12
Max. operating pressure of hydraulic system bar 200
Required hydraulic connections 1x single-action*
1x double-action**
Max. permissible transport speed 40 km/h
Dead weight kg 2800
Permissible axle load kg 1400
Permissible supporting load kg 1400
*) EW= Single-action control unit
**) DW= Double-action control unit
