1 TENSIONING UNIT H46-10000
a. (For H-46A) H46-10010
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
H46-10000 Tensioning Unit (For H-46A, 12mm) 1
H46-10010 Tensioning Unit (For H-46A, 16mm) 1
1 H46-10200 Bracket A 1
2 H46-10300 Swivel Shaft 1
3 H46-10400 Front Gear A 3
4 H46-10500 Cam Disk 1
5 H46-10600 Strap Stop (For 16mm) 1
H46-10610 Strap Stop (For 12mm) 1
6 H46-10700 Tensioning Wheel A 1
7 H46-10800 Tensioning Body 1
8 H46-10900 Gripper 1
9 H46-11010 End Cover 1
10 H46-11100 Shaft 1
11 H46-11200 Strap Stop 1
12 H46-11300 Spur Wheel A 1
13 H46-11500 Tensioning Wheel Shaft A 1
14 H46-11700 Rear Gear A 3
15 H46-12000 Bevel Gear A 1
16 H46-12100 Bevel Gear A 1
17 H46-12400 Bushing 1
18 H46-12500 Strap Stop (For 16mm) 1
H46-12510 Strap Stop (For 12mm) 1
19 H46-13100 Collar 1
20 H46-21410 Collar (φ6) 1
21 H46-51900 Washer 1
30 BRFC0612 Bearing, FC0612 1
31 BR6802ZZ Bearing, 6802ZZ 1
32 BR6807Z Bearing, 6807Z 2
33 BR6902-2RS Bearing, 6902 2RS 1
34 HFL1022 Bearing, 10×14×22 1
35 H42-1212 Spring 1
36 H44-10070 Washer 2
37 MB1010 Metal Bushing, 1010 2
38 MCO-A-183200 Spacer 1
39 MWA-A-140050 Washer 1
40 TLA1015 Needle Bearing, 1015 1
41 SR15 Snap Ring, S-15 1
42 LA-60100 Label 1
-C2-
