2 GRIPPER UNIT H46-20000
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 H46-20200 M2 Bracket 1
2 H46-20300 Shaft 1
3 H46-20400 Eccentric Shaft 1
4 H46-20500 Lever 1
5 H46-20600 Lever 1
6 H46-20700 Upper Linkage 1
7 H46-20800 Shaft 1
8 H46-21000 Lower Linkage 1
9 H46-21100 Shaft 1
10 H46-21310 Bracket 1
11 H46-21400 Collar (φ5) 1
12 H46-21410 Collar (φ6) 1
13 H46-21600 Bushing 2
14 H46-40600 Pin 1
25 H45-20080 M2 Motor 1
26 H45-20090 Micro Switch 2
27 MSP-F-3514001 Spring 1
45 HSS0303N HSS, M3×3 (N) 3
46 HSS0406GN HSS, M4×6 (G)(N) 1
55 PMS0210N PMS, M2×10 (N) 4
60 THS0412N THS, M4×12 (N) 2
65 HBS0308N HBS, M3×8 (N) 1
66 HBS0310N HBS, M3×10 (N) 2
67 HBS0312N HBS, M3×12 (N) 2
70 SW02 SW, M2 4
71 SW03 SW, M3 5
72 SW04 SW, M4 2
75 PW03
PW, M3
2
76 PW06A PW, M6 (A) 1
-C10-
To Next Page
