4 SEALING & CUTTING UNIT H46-40000
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 H46-40100 Motor Support 1
2 H46-40200 Swivel Bracket 1
3 H46-40300 Welding Eccentric 1
4 H46-40400 Motor Support 1
5 H46-40500 Welding Shoe 1
6 H46-40800 Pully 1
7 H46-40900 Cutter 1
8 H46-41000 Welding Stop Grippe
r
1
9 H46-41100 Bolt 1
10 H46-41500 Washer 1
11 H46-41600 Gear 1
12 H46-41700 Washer 1
13 H46-42000 Spring 1
14 H46-42200 Cutter Bushing 1
15 H46-42300 Belt 1
20 H46-10120 M1 Motor A'ssy 1
21 H46-21410 Collar (φ6) 1
30 BRF6-14M Thrust Bearing, F6-14M 1
31 BR607ZZ Bearing, 607ZZ 2
32 HFL0615-I Bearing, 6×10×15 1
33
JTM-0615-015 Thrust Washer 1
34 TA1012 Needle Bearing, 1012 1
35 SB05 Ball, φ54
36 SP0520 Spring Pin, 5×20 1
45 HSS0303N HSS, M3×3 (N) 1
46 HSS0408GN HSS, M4×8 (G)(N) 2
55 FHS0310N
FHS, M3×10 (N)
4
60 THS0410N THS, M4×10 (N) 1
65 HBS0410N HBS, M4×10 (N) 1
