3 LINKAGE UNIT H46-30000
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 H46-30100 Handle Lever 1
2 H46-30200 Handle Cam 1
3 H46-30300 Block 1
4 H46-30400 Toothed Lever 1
5 H46-30600 Pawl Wheel 1
6 H46-30700 Pawl Shaft 1
7 H46-30800 Set Screw 1
8 H46-30900 Spring 1
9 H46-31000 Spring 1
25 H44-10070 Washer 2
26 H45-10250 Washer 1
30 ER03 Snap Ring, E-3 1
31 MB1008 Metal Bushing, 1008 1
32 MB1010 Metal Bushing, 1010 1
33 SB07 Ball, φ72
45 HSS0408GN HSS, M4×8 (G)(N) 2
65 HBS0406N HBS, M4×6 (N) 1
66 HBS0516N HBS, M5×16 (N) 1
67 HBS0608N HBS, M6×8 (N) 1
75 PW04 PW, M4 1
-C12-
