Kronos H-46B - Body Frame Unit

5 BODY FRAME UNIT H46-50000
H46-50010
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
H46-50000
Body Frame Unit (For H-46A)
1
H46-50010
Body Frame Unit (For H-46B)
1
1 H46-50100 Body Frame (For H-46A) 1
H46-50110 Body Frame (For H-46B) 1
2 H46-50300 Suspension Bracket (Option) 1
3 H46-50800 Cover Front 1
4 H46-50900 Cover Rear 1
5 H46-51000 M1 Cover Upper 1
6 H46-51200 Cover 1
7
H46-51210
Cover 1
8 H46-51500 Bottom Base Wearing Protection Plate
(Option)
1
9 H46-51800 Bottom Base Protection Plate (Option) 1
10 H46-52000 Bottom Base Protection Plate 1
11 H46-52100 Bottom Base Wearing Protection Plate
Set (Option)
1
12 H46-52200 Suspension Bracket Set (Option) 1
25 LA-60120 Label 1
30 MB0810 Metal Bushing, 0810 (For H-46A) 1
MB0812 Metal Bushing, 0812 (For H-46B) 1
50 FHS0410N FHS, M4×10 (N)(Option) 6
55 TMS0410N TMS, M4×10 (N) 3
56 TMS0420N TMS, M4×20 (N) 2
60 TTP0312BN TTP, M3×12 (B)(N) 4
61 TTP0425BN TTP, M4×25 (B)(N) 6
65 HBS0516N HBS, M5×16 (N)(Option) 2
70 SW05 SW, M5 (Option) 2
-C18-
