1 TENSIONING UNIT H46-10020
b. (For H-46B) H46-10030
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
45 HSS0303N HSS, M3×3 (N) 2
46 HSS0305 HSS, M3×5 1
47
HSS0406GN HSS, M4×6 (G)(N) 3
55 FHS0308N FHS, M3×8 (N) 2
56 FHS0410N FHS, M4×10 (N)(Only 16mm) 1
60 THS0405N THS, M4×5 (N) 1
61 THS0408N THS, M4×8 (N) 1
62 THS0412N THS, M4×12 (N)(Only 16mm) 1
65 HBS0412N HBS, M4×12 (N) 8
70 SW04 SW, M4 8
-C7-
