Submersible Motor Pumps (150 mm and above)
10
12. Recommended spare parts for 2 years of operation
12.1 Pump
No. of pumps including standby pumps
Part No. Description 1 2 4 5 6 8 10 & above
Quantity of spare parts
143 Suction strainer 1 1 1 2 2 2 3
502 Wearing ring (set) 1 1 2 2 2 2 3
521 Stage sleeve (set) 1 1 1 1 2 2 3
524 Shaft protection sleeve - Oil seal 1 1 1 2 2 2 3
529 Bearing sleeve (set) 1 1 1 1 2 2 3
545 Bearing bush - Rubber 1 1 2 2 2 2 3
545.01 Bearing bush (LTB4) 1 1 2 2 2 2 3
752 Valve seat with O-ring 1 1 1 1 2 2 3
---- Set of gasket & O-ring 1 1 2 2 2 3 3
12.2 Motor
No. of pumps including standby motors
Part No. Description 1 2 3 4 5 6 8 10 & above
Quantity of spare parts
271 Sand guard 1 1 1 1 2 2 3 4
412 O rings 1 1 1 2 2 2 3 4
421 Oil seal 1 1 1 2 2 2 3 4
829 Cable packing ring 1 1 1 1 2 2 3 3
829 Cable gland ring 1 1 1 1 2 2 3 3
903 Drain plug 1 1 1 1 2 2 3 3
932 Circlip 1 1 1 1 2 2 3 3
411 Gasket (set) 1 1 1 2 2 3 3 4
550 Washer (set) 1 1 1 2 2 3 3 4
384 Thrust bearing plate 1 1 1 1 2 2 2 3
387 Thrust bearing segment (set) 1 1 1 1 2 2 3 4
59.12 Diaphragm 1 1 1 2 2 3 3 4
