GP800 UPS Communication interface
- 33 -
8.4 UPS’ hardware equipment
RS232 appearance, figure 38
The pin of UPS’ RS is the following:
PIN2: RS232 RXD
PIN3: RS232 TXD
PIN5: GND
Figure 38
