SPECIFICATION GP800 UPS
- 34 -
9 SPECIFICATION
Model 1KVA 2KVA 3KVA 4KVA 6KVA 8KVA 10KVA
AC input
Voltage 176~264VAC
Frequency 50(60) Hz ±5%
Phase Single
Max. Current 6A 10A 14A 24A 34A 45A 56A
AC output
Voltage 220V(230V)
Frequency 50(60) Hz
Voltage
stability
±1%
Frequency
stability
±0.5 (Disconnection)
Wave form SPWM sine wave
Power factor 0.8
Distortion <3%(linear load)
Battery
Voltage 48VDC 192VDC
Model Lead acid free from maintenance,
Offer time Refer to figure 31
Charging
time
90% capacity after 8-10 hours
Alarm
Utility
disconnect
Buzzer beeps once every four seconds
Battery
exhausted
Buzzer beeps once every one second
Overload Load indicator light is solid on, buzzer continuously beeps for long-time.
UPS
abnormal
Fault indicator light is solid on, buzzer continuously beeps for long-time.
