INSTALLATION GP800 UPS
- 12 -
Simple identification way to power polarity:
(1) Line (L): There is 220V relative to other two holes.
(2) Neutral (N): there is 220V relative to the Line, there is 0.5-2V
relative to the ground.
(Load current circulate through neutral)
(3) Ground (G): Please find out correct connecting point to the ground
in the switchboard.
7. If the difference between the neutral and the ground is more than 5V
or it can’t meet the requirement of system, please reinstall good
grounding system to keep safety of system operation.
8. The comparison list of input current rating and input cable size is as
follows:
Model Max. input current Input wire Terminal specification
GP801 5A 12AWG 5.5~6
GP802 10A 10AWG 5.5~6
GP803 15A 10AWG 5.5~6
GP804 20A 10AWG 5.5~6
GP805 25A 10AWG 5.5~6
GP806 30A 10AWG 5.5~6
GP808 40A 8AWG 8.5~9
GP810 50A 8AWG 8.5~9
GP812 60A 8AWG 8.5~9
9. The power cable and the impaction terminal must be first grade
product manufactured by authentic manufacturer. Prohibit use spent
and inferior product.
10. The power cable must be impacted by impaction terminal of authentic
manufacturer, prohibit directly wrapping power cable to the terminal
plate.
11. After fastening input cable, please see if the input cable contacts with
protection cover and avoid short-circuit.
12. Please turn off power when connecting cable, prohibit operation on
live and keep safety.
