CONFIGURATION AND FUNCTION GP800 UPS
- 4 -
4) Display of input frequency value
ON LINE
OUTPUT: 220V
5) Display of output frequency value
ON LINE
OUTPUT FRE: 50HZ
6) Display of output power Percent
ON LINE
LOAD: 100%
7) Display of battery voltage value
ON LINE
BATTERY: 218V
8) Temperature display in machine
ON LINE
TEMP: 33℃
*These parameters vary with machine model.
9) LCD cycle display switch button: digital signal display items
switch button.
10) UPS switch button: UPS general switch button.
(1) Turn on UPS inverter by pressing the “ON” key. UPS
convert to UPS inverter power output 20s later, UPS pure
AC output power is supplied by UPS internal power
supply equipment.
(2) Turn off UPS inverter by pressing the “OFF” button. UPS
convert to utility bypass.
The button acts as general switch mainly.
2.2 Appearance
