 OutputInformation  

Indicateoutputvoltage,outputfrequency,loadpercent,loadinVA,
loadin
Wattanddischargingcurrent.
 BatteryInformation 

Indicatesbatterylevelby0-24%,25-49%,50-74%and75-100%in
batterymodeandchargingstatusinlinemode.
InACmode,itwillpresentbatterychargingstatus.
Status Batterycapacity LCDDisplay
Constant
Currenmode
0-24%
4barswillflashinturns
25-49%
Bottombarwill be on and the other three
barswillflashinturns
50-74%
Bottomtwobarwillbeonandtheothertwo
barswillflashinturns
75-100%
Bottomthreebarwillbeonandthetopbars
willflash 


  LoadInformation  

Indicatesoverload.





Indicatestheloadlevelby0-24%,25-50%,50-74%and75-100%.
0%~25% 25%~50% 50%~75% 75%~100%
 
  ModeOperationInformation 



Indicatesunitconnectstothemains.

Indicatesloadissuppliedbyutilitypower.

Indicatestheutilitychargercircuitisworking.

IndicatestheDC/ACinvertercircuitisworking.
  MuteOperation  

Indicatesunitalarmisdisabled.
