2-4 UPSstartupandturnoff

 Startupoperation

(1)TurnontheUPSinlinemode

NOTE Verify that the total equipment ratings do not exceed the UPS

capacitytopreventanoverloadalarm.

a) Oncemainspowerispluggedin,theUPSwillchargethebattery,atthemoment,

theLCDshowsthattheoutputvoltageis220,whichmeanstheUPSautomatically

tarttheinverter.Ifitisexpectedtochangetobypass

model,youcanPress“OFF”

key.

b) PressandholdtheONkeyformorethan

threesecondstostarttheUPS,thenitwill

starttheinverter.

c) Oncestarted,theUPSwillperformaself-testfunction,LEDwilllightandgoout

circularly and orderly. When the self-test finishes, it will come to line mode, the

correspondingLEDlights,theUPSisworkinginlinemode.

(2)TurnontheUPSbyDCwithoutmainspower

a) Whenmainspowerisdisconnected,pressandholdtheONkeyformorethanhalfa

secondtostartUPS.

b) TheoperationoftheUPSintheprocessofstartisalmostthesameasthatwhen

mainspowerisin.Afterfinishingtheself-test,thecorrespondingLEDlightsandthe

UPSisworkinginbatterymode.

 Turnoffoperation

(1) TurnofftheUPSinlinemode

a) PressandholdtheOFFkeyformorethanhalfasecondtoturnoff theUPS and

inverter.

b) AftertheUPSshutdown,theLEDsgooutandthereisnooutput. If output is

needed,youcansetbps“ON”ontheLCDsettingmenu.

(1) TurnofftheUPSbyDCwithoutmainspower

a) PressandholdtheOFFkeyformorethanhalfasecondtoturnofftheUPS.

b) WhenturningofftheUPS,itwilldoself-testingfirstly.TheLEDslightandgoout

circularlyandorderlyuntilthereisnodisplayonthecover.

Operation and Display Panel

Theoperationanddisplaypanel,showninbelowchart,isonthefrontpanelofthe

inverter.Itincludesthreeindicators,fourfunctionkeysandaLCDdisplay,indicatingthe

operatingstatusandinput/outputpowerinformation.
