LCD control panel introduction
（1）LED（fromright  toleft:“alarm”,“bypass”,“battery”,“inverter”);
（2）On-LineUPSLCDdisplay;（3）Functionkeys

 LED Indicator
Indicator Description

Red

OnTheUPShasanactivealarmorfault.


Yellow
TheUPSisinBypassmode.
OnTheUPSisoperatingnormallyonbypass
duringHighEfficiencyoperation.

Yellow

OnTheUPSisinBatterymode.


Green

OnTheUPSisoperatingnormally.

NOTE   Whenpoweronorstartup,theseindicatorswillturnonandoffsequentially.
NOTE   Ondifferentoperationmodes,theseindicatorswillindicatedifferently. 
