KStar UDC9101S One User Manual

11
Function Keys
FunctionKey Description
ESC/OFF ToexitsettingmodeOrturnofftheups
UP TogotopreviousselectionOrturnontheups
Down Togotonextselection
ENTER/ON Toconfirmtheselectioninsettingmodeorentersettingmode
LCD Display Icons
Icon  Function description 
 InputSourceInformation  

IndicatestheACinput.

Indicate input voltage, input frequency, PV voltage, battery
voltageandTemp
 ConfigurationProgramandFaultInformation  

Indicatesthesettingprograms.

Indicatesthewarningandfaultcodes.
Warning:
 flashingwithwarningcode. 
Fault:lightingwithfaultcode

