CONTROLS 6
21
6.14 RACE-ON button
V02599-13
The RACE-ON button
1
is fitted on the right side of the combi-
nation switch.
Info
The RACE-ON button performs the ignition lock function on
this vehicle.
The steering can only be locked if the handlebar is turned
to the left.
Possible states
• RACE-ON button in the basic position.
• RACE-ON button pressed briefly – Pressing briefly switches
the ignition on and unlocks the steering lock or switches the
ignition off. The RACE-ON indicator lamp lights up briefly
once for confirmation.
• RACE-ON button pressed and held – Pressing and holding
switches the ignition off and locks the steering lock.
6.15 C1 and C2 switch
V02600-10
The C1 and C2 switch is fitted on the right of the combination
switch.
Info
The C1 and C2 switch enables quick access to various
menus.
The C1 and C2 switch can be freely configured.
6.16 RACE-ON key
S01724-10
In this vehicle, the RACE-ON key
1
performs all the functions of
the conventional ignition key.
Press the
2
button to fold out the key bit. The key bit it is only
used for unlocking the seat lock and for opening the cases (option-
al).
The black ignition key
3
is only intended for situations in which
the RACE-ON key is not available or is not functional.
The black ignition key can be used to start the vehicle if the
RACE-ON key battery voltage is too low and the transponder is not
recognized by the vehicle. The black Race-on key can also be used
to unlock the seat lock and open the cases (optional).
Info
The ignition keys contain electronic components. Always
maintain a distance of several centimeters to other devices
with electronic components.
A lost ignition key must be deactivated by an authorized KTM
workshop to prevent unauthorized persons from operating the vehi-
cle.
The ignition keys supplied are activated when delivered.
