KTM 1290 Super Duke R 2018 User Manual

19 SERVICE WORK ON THE ENGINE
258
E00672-10
–
Mount and tighten oil drain plugs
1
with the magnets, O-
rings, and oil screens.
Guideline
Oil drain plug M20x1.5 20 Nm (14.8 lbf ft)
E00671-11
– Have the entire filling quantity available.
Engine oil
Outside temperature:
≥ 0 °C (≥ 32 °F)
3.50 l
(3.7 qt.)
Engine oil
(SAE 10W/50)
( p. 302)
Engine oil
Outside temperature:
< 0 °C (< 32 °F)
Engine oil (SAE
5W/40) ( p. 303)
– Add the oil quantity quantity in two separate operations.
–
Remove screw plug
5
and fill up with initial partial quantity.
Engine oil (1st par-
tial quantity) approx.
Outside temperature:
≥ 0 °C (≥ 32 °F)
3.0 l (3.2 qt.) Engine oil
(SAE 10W/50)
( p. 302)

KTM 1290 Super Duke R 2018 Specifications

General

Engine Type	2-cylinder, 4-stroke, V 75°
Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 3 oil pumps
Front Suspension	WP USD Ø 48 mm
Rear Suspension	WP monoshock
Traction Control	MTC (Motorcycle Traction Control)
Ground Clearance	140 mm
Seat Height	835 mm
Fuel Capacity	18 liters
Dry Weight	189 kg
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Power	177 hp (130 kW) @ 9, 750 rpm
Torque	141 Nm @ 7, 000 rpm
Fuel System	Electronic fuel injection
Frame	Chromoly steel trellis frame, powder coated
Front Brake	2 x Brembo, 320 mm
Rear Brake	Brembo twin-piston fixed caliper, 240 mm
Wheelbase	1482 mm
