KTM 1290 Super Duke R 2018 - Chassis Tightening Torques

TECHNICAL DATA 23
289
Gas pressure 10 bar (145 psi)
Static sag
Standard 20 mm (0.79 in)
Race track mode 14 mm (0.55 in)
Fitted length 384 mm (15.12 in)
Shock absorber fluid ( p. 303) SAE 2.5
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOT PT
®
K45x12 1 Nm (0.7 lbf ft)
Screw, air filter box cover EJOT PT
®
K60 2 Nm (1.5 lbf ft)
Screw, combination switch, left 5 Nm (3.7 lbf ft)
Screw, fastening, flue exhaust
valve cover
EJOT SF
®
M4x6‑K 4 Nm (3 lbf ft)
Screw, fuel tank cover, quick con-
nect nipple
EJOT PT
®
K60 2 Nm (1.5 lbf ft)
Screw, tail light EJOT PT
®
K50x14 2.5 Nm (1.84 lbf ft)
Screw, fixed grip, left M4 2 Nm (1.5 lbf ft)
