4 TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 12

Nut, shift rod M8 12 Nm (8.9 lbf ft) –

Nut, shift rod M8LH 12 Nm (8.9 lbf ft) –

Nut, valve, angled M8 4 Nm (3 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, axle clamp M8 15 Nm (11.1 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, foot brake lever M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite

2701™

Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, ignition lock (tamper-proof

screw)

M8 25 Nm (18.4 lbf ft) –

Screw, rear brake caliper M8 25 Nm (18.4 lbf ft) Loctite

2701™

Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, shift lever on footrest bracket M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, shift shaft deflector on frame M8 10 Nm (7.4 lbf ft) Loctite

243™

Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, side stand spring M8 15 Nm (11.1 lbf ft) Loctite

2701™

Screw, steering damper on holder M8 8 Nm (5.9 lbf ft) Loctite

243™

Screw, steering damper on triple clamp M8 8 Nm (5.9 lbf ft) Loctite

243™

Screw, top triple clamp M8 15 Nm (11.1 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, engine bearer M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, front brake caliper M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, instrument support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite

243™

Screw, side stand bracket M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, side stand retaining plate M10 45 Nm (33.2 lbf ft) Loctite

243™

Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) –

Banjo bolt, brake line, connecting

piece, rear

M10x1 15 Nm (11.1 lbf ft) –

Nut, rear hub shock absorber carrier M10x1.25 45 Nm (33.2 lbf ft) Loctite

243™

Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –

Screw, bottom shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased

Screw, top shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased

Screw, eccentric M16 70 Nm (51.6 lbf ft) –

Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased

Nut, seat lock M22x1.5 6 Nm (4.4 lbf ft) –

Screw, steering head, top M22x1.5 50 Nm (36.9 lbf ft) –

Bolt, front axle M25x1.5 45 Nm (33.2 lbf ft) Thread greased

Nut, steering head M28x1.0 Step 1

10 Nm (7.4 lbf ft)

Step 2 (loosen, counter-

clockwise)

60°

–

Nut, rear axle, shock absorber side M35x1.5 200 Nm (147.5 lbf ft) Loctite

262™/lock the lock-

ing wire with locking varnish

Nut, rear axle M50x1.5 250 Nm (184.4 lbf ft) Lock the locking wire with

locking varnish
