ENGLISH
9
Compression damping of shock absorber
With the knob 1 the degree of damping of the compression can be adju-
sted to 7 positions. Turn the knob counterclockwise to increase damping,
turn it clockwise to reduce damping during compression.
BASIC SETTING
– WP 01.18.Q7.81 (K4T96S).........position 3
Rebound damping of shock absorber
With the setting wheel 2 the degree of damping of the rebound can be
adjusted to 11 positions. Turn the knob to the left side to increase dam-
ping, turn it to the right side to reduce damping during rebounding.
BASIC SETTING:
– WP 01.18.Q7.81 (K4T96S).........position 4
WARNING
–NEVER CHANGE DAMPING BETWEEN THE TEST DRIVES MORE THAN 2 CLICKS.
–T
HE DAMPING UNIT OF THE SHOCK ABSORBER IS FILLED WITH HIGHLY COMPRESSED
NITROGEN
. NEVER TRY TO TAKE THE SHOCK ABSORBER APART OR TO DO ANY MAIN
-
TENANCE WORK YOURSELF. SEVERE INJURIES COULD BE THE RESULT.
Baggage carrier
The baggage carrier may be loaded with up to 10 kg. The two lateral
hoops serve as handles for the passenger
1
2
