22 TECHNICAL DATA 95
22.2 Engine tightening torques
Nozzle, crank chamber ventilation M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Oil nozzle for alternator cooling M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Oil nozzle for balancer shaft lubrication M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Oil nozzle for clutch lubrication M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Oil nozzle for conrod bearing lubrica-
tion
M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Screw, oil nozzle for piston cooling M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Locking screw for bearing M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Oil channel screw plug in alternator
cover
M5 1.2 Nm (0.89 lbf ft) Loctite
®
648™
Oil nozzle for cam lever lubrication M5 3 Nm (2.2 lbf ft) Loctite
®
243™
Oil nozzle, piston cooling M5 2 Nm (1.5 lbf ft) Loctite
®
243™
Screw, bearing bolt, oil pump idler
gear
M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, crankshaft position sensor M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, gear position sensor M5 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, oil pump cover M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Nut, cylinder head M6 10 Nm (7.4 lbf ft) Lubricated with engine oil
Nut, water-pump wheel M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, alternator cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft) –
Screw, clutch spring M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6 10 Nm (7.4 lbf ft) –
Screw, exhaust flange M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft) –
Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) –
Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, valve cover M6 8 Nm (5.9 lbf ft) –
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Stud, cylinder head M6 10 Nm (7.4 lbf ft) –
Screw, camshaft bearing bridge M7x1 14 Nm (10.3 lbf ft) Lubricated with engine oil
Screw plug, crankshaft location M8 10 Nm (7.4 lbf ft) –
Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft) Loctite
®
243™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft) Loctite
®
2701™
Plug, oil channel M10x1 15 Nm (11.1 lbf ft) Loctite
®
243™
Rotor screw M10x1 70 Nm (51.6 lbf ft) Thread, oiled with engine
oil/cone degreased
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft) –
Screw, unlocking of timing chain ten-
sioner
M10x1 8 Nm (5.9 lbf ft) –
Spark plug M10x1 10… 12 Nm (7.4…
8.9 lbf ft)
–
Engine coolant temperature sensor M10x1.25 12 Nm (8.9 lbf ft) –
