6 CONTROLS 17

6.18 Fuel tap

602702-10

The fuel tap is on the left side of the fuel tank.

Tap handle 1 on the fuel tap is used to open or close the supply of fuel to the carbure-

tor.

Possible states

• Fuel supply closed OFF – Fuel cannot flow from the fuel tank to the carburetor.

• Fuel supply open ON – Fuel can flow from the fuel tank to the carburetor. The fuel

tank empties to the point of reserve capacity.

• Open the fuel reserve supply RES – Fuel can flow from the fuel tank to the carbu-

retor. The fuel tank empties fully.

6.19 Choke

B00004-10

The choke lever 1 is fitted on the left side of the carburetor.

Activating the choke function frees an opening in the carburetor through which the

engine can draw extra fuel. This creates a richer fuel-air mixture, as is required for a

cold start.

Info

If the engine is warm, the choke function must be deactivated.

Possible states

• Choke function activated – The choke lever is pulled out all the way.

• Choke function deactivated – The choke lever is pushed in all the way.

6.20 Shift lever

B01149-10

Shift lever 1 is mounted on the left side of the engine.

B01149-11

The gear positions can be seen in the photograph.

The neutral or idle position is between the first and second gears.
