4 TECHNICAL DATA
16
Screw, rear brake caliper M8 18 Nm (13.3 lbf ft)
Loctite
®
243™
Screw, rear sprocket M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, subframe M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Steering stem clamp screw M8 20 Nm (14.8 lbf ft)
Engine carrying screw M10 45 Nm (33.2 lbf ft)
Nut, foot brake lever M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, bottom shock absorber M12 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Screw, top shock absorber M12 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Nut, seat fixing M12x1 20 Nm (14.8 lbf ft)
Nut, swingarm pivot M14x1.5 75 Nm (55.3 lbf ft)
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
