3 ARBEITEN
12
3.5 Installing front fender
S05339-10
Main work
–
Position front fender. Mount and tighten screws
1
and
2
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
Finishing work
– Install the start number plate. ( p. 12)
3.6 Removing the start number plate
S05336-10
–
Remove screw
1
.
– Unhook the start number plate from the brake line and remove
it.
3.7 Installing the start number plate
S05337-10
–
Position the brake line in holders
A
on the start number
plate.
–
Position the start number plate. Mount and tighten screw
1
.
The holding lugs engage in the fender.
