TECHNICAL DATA 4
21
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, seat fixing M6 8 Nm (5.9 lbf ft)
Screw, starter cable to starter relay M6 6 Nm (4.4 lbf ft)
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft)
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Nut, rim lock M8 12 Nm (8.9 lbf ft)
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft)
Remaining screws, chassis M8 25 Nm (18.4 lbf ft)
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, manifold on cylinder head
brace
M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment
(All XC‑F models)
M8 33 Nm (24.3 lbf ft)
Loctite
®
2701™
Screw, subframe bottom M8 30 Nm (22.1 lbf ft)
Loctite
®
2701™
Screw, subframe top M8 35 Nm (25.8 lbf ft)
Loctite
®
2701™
Screw, top steering stem M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Engine carrying screw M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Nut, angle lever to link fork M16x1.5 60 Nm (44.3 lbf ft)
Nut, fork pivot M16x1.5 100 Nm (73.8 lbf ft)
Nut, frame on linkage lever M16x1.5 60 Nm (44.3 lbf ft)
Nut, linkage lever on angle lever M16x1.5 60 Nm (44.3 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Nut, rear wheel spindle M22x1.5 80 Nm (59 lbf ft)
Screw-in fitting, cooling system M24x1.5 7.5 Nm (5.53 lbf ft)
