23 TECHNICAL DATA 121
Nut, inner clutch hub M18x1.5 80 Nm (59 lbf ft) –
Nut, primary gear M20LHx1.5 100 Nm (73.8 lbf ft)
Loctite
®
648™
Screw plug, engine oil screen M20x1.5 15 Nm (11.1 lbf ft) –
Screw plug, gear oil screen M20x1.5 15 Nm (11.1 lbf ft) –
23.3 Capacities
23.3.1 Capacity - engine oil
Engine oil 1.20 l (1.27 qt.) Engine oil (SAE 10W/50) ( p. 126)
Alternative engine oil for harsh
operating conditions and
increased performance
Engine oil (SAE 10W/60)
(00062010035) ( p. 126)
23.3.2 Capacity - coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 126)
Coolant (mixed ready to use) ( p. 126)
23.3.3 Capacity - fuel
Total fuel tank capacity,
approx. (all EXC models)
9 l (2.4 US gal) Super unleaded (ROZ 95/RON 95/PON 91) ( p. 127)
Total fuel tank capacity,
approx. (all XC‑W models)
8.5 l (2.25 US gal) Super unleaded (ROZ 95/RON 95/PON 91) ( p. 127)
Fuel reserve, approx. 1.5 l (1.6 qt.)
23.4 Chassis
Frame Central tube frame made of chrome molybdenum steel tubing
Fork (EXC EU, EXC AUS, all XC‑W models) WP Suspension Up Side Down 4860 MXMA PA
Fork (EXC SIX DAYS) WP Suspension Up Side Down 4860 4CS
Suspension travel
Fork offset 20 mm (0.79 in)
Shock absorber WP Suspension PDS 5018 DCC
Brake system Disc brakes, brake calipers on floating bearings
Brake discs - diameter
Front 260 mm (10.24 in)
Rear 220 mm (8.66 in)
Brake discs - wear limit
Front 2.5 mm (0.098 in)
Rear 3.5 mm (0.138 in)
Tire air pressure off road
Front 1.0 bar (15 psi)
Rear 1.0 bar (15 psi)
Road tire pressure (all EXC models)
Front 1.5 bar (22 psi)
Rear 1.5 bar (22 psi)
Final drive (all 450 EXC models) 14:52 (13:52)
Final drive (all 500 EXC models) 14:50 (13:50)
Final drive (450 XC-W USA) 14:52 (13:52)
Final drive (500 XC-W USA) 14:50 (13:50)
Chain 5/8 x 1/4"
Rear sprockets available 38, 40, 42, 45, 48, 49, 50, 51, 52
Steering head angle 63.5°
Wheelbase 1,482±10 mm (58.35±0.39 in)
