KTM 60 SX - Technical Specifications - Chassis 65 SX 2000

ENGLISH
24
Spring 2,91 N/mm
Preload bushing - length 80 mm
Oil capadity per fork leg 170 ccm
Fork oil SAE 7,5
STANDARD ADJUSTMENT – FORK
WP 0318U706
Compression adjuster 3
Rebound adjuster 6
Spring 40-220
Spring preload 7mm (0.3 in)
S TANDARD A DJUSTMENT - S HOCK A BSORBER
Frame single downtube, split-cradle
Fork telescopic fork (Paioli)
Wheel travel front/rear 200 mm (8 in) / 230 mm (9.2 in)
Rear suspension central shock absorber (White Power)
Front brake Disc brake Ø 198 mm (7.8 in), 1 piston
Rear brake Disc brake Ø 160 mm (6.3 in), 1 piston
Tyres front: 60/100-14“ rear: 80/100-12“
Air pressure front / rear: 1.0 bar (14 psi) / 1.0 bar (14 psi)
Fuel tank capacity 3.5 liter (0,92 USgal)
Final drive ratio 12 : 46 t
Chain 1/2 x 1/4" (415) 108 rolls
Steering angle 63.5 °
Wheel base 1128 mm (44,4 in)
Seat height, unloaded 740 mm (29,1 in)
Ground clearance 265 mm (10,4 in)
Dead weight without fuel 52 kg (114,8 lbs)
Rider’s body height max. 160 cm (63 in)
Rider’s body weight max 50 kg (22,7 lbs)
Recommended age of rider 8 to 12 years
Engine CR63
TECHNICAL SPECIFICATIONS – CHASSIS 65 SX 2000
Hexagon screw - brake caliper M 8 Loctite 242 + 20 Nm 15 ft.lb.
Flat head screw - brake discs M6 Loctite 242 + 10 Nm 7 ft.lb.
Hexagon nut - front wheel spindle M 12x1 50 Nm 37 ft.lb.
Hexagon nut - rear wheel spindle M 12x1 50 Nm 37 ft.lb.
Hexagon nut - swingarm bolt M 12x1 50 Nm 37 ft.lb.
Clamping screws - upper fork bridge M 8 15 Nm 11 ft.lb.
Clamping screws - lower fork bridge M 8 15 Nm 11 ft.lb.
AH screw - handlebar clamp M 8 20 Nm 15 ft.lb.
Other screws chassis M 5 6 Nm 4,5 ft.lb.
M 6 10 Nm 7 ft.lb.
M 8 25 Nm 18 ft.lb.
M 10 40 Nm 30 ft.lb.
TIGHTENING TORQUES
