STORAGE
181
15.2
Putting
into
operation
after
storage
–
Raise
the
vehicle
off
of
the
center
stand.
(
p.
66)
–
Recharge
the
battery.
x
(
p.
114)
–
Install
the
battery.
x
(
p.
113)
–
Set
the
clock.
(
p.
29)
–
Refuel.
(
p.
59)
–
Carry
out
checks
before
putting
into
operation.
(
p.
48)
–
Take
a
test
ride.
182
184
Table of Contents
Table of Contents
5
Means of Representation
9
Important Information
10
View of Vehicle
14
View of Vehicle, Front Left Side (Vehicle Differs Slightly from Photo)
14
View of Vehicle, Rear Right Side (Vehicle Differs Slightly from Photo)
16
Location of Serial Numbers
18
Chassis Number
18
Type Label
18
Key Number
19
Engine Number
19
Fork Part Number
20
Shock Absorber Part Number
20
Controls
21
Clutch Lever
21
Hand Brake Lever
21
Light Switch
22
Headlight Flasher Switch
22
Turn Signal Switch
23
Horn Button
23
Ignition/Steering Lock
24
Immobilizer
24
Emergency off Switch
25
Electric Starter Button
25
Combination Instrument
26
Combination Instrument - Function Buttons
26
Combination Instrument - Tachometer
27
Combination Instrument - Indicator Lamps
27
Combination Instrument - Display
28
Combination Instrument - Speedometer
29
Setting Kilometers or Miles
29
Combination Instrument - Time
30
Setting the Clock
31
Combination Instrument - Display ODO
31
Combination Instrument - Setting/Resetting TRIP 1
32
Combination Instrument - Setting/Resetting TRIP 2
32
Combination Instrument - TRIP F Display
33
Combination Instrument - Ambient Temperature Display
34
Setting the Temperature Unit of Measure
34
Combination Instrument - Warning of Slippery Roads
35
Combination Instrument - Coolant Temperature Indicator
35
Socket for Electrical Accessories
36
Hazard Warning Flasher Switch/Hazard Warning Flasher
36
Opening the Filler Caps
37
Closing the Filler Caps
37
Seat Lock
38
Unlocking the Storage Compartment
38
Locking the Storage Compartment
39
Opening the Storage Compartment
39
Closing the Storage Compartment
40
Handrails
40
Luggage Rack Plate
41
Fuel Taps
41
Foot Brake Lever
42
Shift Lever
42
Side Stand
43
Center Stand
44
Passenger Footrests
44
Tool Set
45
General Tips and Hints on Putting into Operation
46
Information on First Use
46
Running in the Engine
47
Loading the Vehicle
48
Riding Instructions
50
Checks before Putting into Operation
50
Starting
51
Starting up
53
Shifting, Riding
53
Braking
57
Stopping, Parking
59
Refueling
61
Service Schedule
64
Maintenance Work on Frame and Engine
67
Jacking up the Vehicle on the Center Stand
67
Raising the Vehicle off of the Center Stand
68
Removing the Seat
68
Mounting the Seat
69
Fork/Shock Absorber
69
Adjusting the Compression Damping of the Fork
70
Adjusting the Rebound Damping of the Fork
71
Adjusting the Spring Preload of the Fork
72
Compression Damping of the Shock Absorber
73
Adjusting the Low-Speed Compression Damping of the Shock Absorber
73
Adjusting the High-Speed Compression Damping of the Shock Absorber
75
Adjusting the Rebound Damping of the Shock Absorber
76
Adjusting the Spring Preload of the Shock Absorber
78
Bleeding the Fork Legs
79
Cleaning the Dust Boots of the Fork Legs
79
Checking the Steering Head Bearing Play
80
Checking for Chain Dirt
82
Cleaning the Chain
82
Checking the Chain Tension
83
Adjusting the Chain Tension
84
Checking the Chain, Rear Sprocket and Engine Sprocket
86
ABS / Antilock Brake System (990 Adventure)
89
Checking the Brake Discs
90
Checking the Free Travel of the Hand Brake Lever
91
Adjusting the Free Travel of the Hand Brake Lever
91
Checking the Front Brake Fluid Level
92
Adding Front Brake Fluid
93
Checking the Front Brake Linings
95
Checking the Free Travel of the Foot Brake Lever
95
Checking the Rear Brake Fluid Level
96
Adding Rear Brake Fluid
97
Checking the Rear Brake Linings
99
Removing the Front Wheel
100
Installing the Front Wheel
102
Removing the Rear Wheel
104
Installing the Rear Wheel
106
Checking the Rear Hub Rubber Dampers
108
Checking the Tire Condition
109
Checking the Tire Air Pressure
110
Checking Spoke Tension
111
Removing the Underride Guard
112
Installing the Underride Guard
113
Removing the Battery
113
Installing the Battery
115
Recharging the Battery
116
Removing the Right Underride Guard
119
Installing the Right Underride Guard
119
Changing the Main Fuse
120
Changing the ABS Fuses (990 Adventure)
122
Changing the Fuses in the Fuse Box
123
Removing the Front Side Cover
126
Installing the Front Side Cover
126
Removing the Headlight Mask with the Headlight
127
Installing the Headlight Mask with the Headlight
128
Changing the High Beam Bulb
128
Changing the Low Beam Bulb
129
Changing the Parking Light Bulb in the Headlight
130
Changing the Turn Signal Bulb
131
Changing the Tail Light Bulb
132
Changing the Brake Light Bulb
133
Checking the Headlight Setting
134
Adjusting the Headlight Range
135
Activating/Deactivating the Ignition Key
135
Removing the Storage Compartment and Hanging It to One Side
138
Installing the Storage Compartment
139
Removing the Left Fuel Tank
140
Installing the Left Fuel Tank
141
Cooling System
143
Checking the Coolant Level in the Compensating Tank
144
Checking the Antifreeze and Coolant Level
145
Draining the Coolant
148
Filling/Bleeding the Cooling System
149
Removing the Radiator Guard
152
Installing the Radiator Guard
153
Adjusting the Basic Setting of the Clutch Lever
154
Checking/Rectifying the Fluid Level of the Hydraulic Clutch
154
Checking the Play in the Throttle Cable
155
Adjusting the Play in the Throttle Cable
156
Checking the Engine Oil Level
156
Changing the Engine Oil and Filter, Cleaning the Oil Screens
157
Draining Engine Oil, Cleaning Oil Screens
157
Removing the Oil Filter
161
Installing the Oil Filter
163
Filling up with Engine Oil
163
Adding Engine Oil
165
Ignition Curve Plug-In Connector
166
Adjusting the Ignition Curve to the Fuel Quality
166
Immobilizer Blink Code
168
Engine Control Blink Code
170
Troubleshooting
176
Cleaning
179
Cleaning Motorcycle
179
Protective Treatment for Winter Operation
181
Storage
182
Putting into Operation after Storage
183
Technical Data - Engine
184
Capacity- Engine Oil
185
Capacity - Coolant
185
Technical Data - Engine Tightening Torques
186
Technical Data - Chassis
190
Lighting Equipment
192
Tires
193
Capacity - Fuel
193
Technical Data - Fork
194
990 Adventure
194
990 Adventure R
195
Technical Data - Shock Absorber
197
990 Adventure
197
990 Adventure R
198
Technical Data - Chassis Tightening Torques
200
Substances
203
Auxiliary Substances
207
Standards
209
