9-40C
Collar screw, front wheel spindle M 24x1,5 40 Nm
Brake caliper, front M 8 Loctite 243 + 25 Nm
Brake disk, front M 6 10.9 Loctite 243 + 15 Nm
Brake disk, rear M 6 Loctite 243 + 15 Nm
Clamping screws, upper fork bridge M 8 20 Nm
Clamping screws, lower fork bridge M 8 15 Nm
Clamping screws, fork stubs M 8 10 Nm
Collar nut, rear wheel spindle M 20x1,5 80 Nm
Hexagon nut, swing arm bolt M 14x1,5 100 Nm
Hexagon collar screw, handlebar clamp M 8 20 Nm
Allan head screw, handlebar support M 10 Loctite 243 + 40 Nm
Shock absorber, top M 12 60 Nm
Shock absorber, bottom M 12 60 Nm
Sprocket screws M 8 Loctite 243 + 35 Nm
Ball joint for push rod M 6 Loctite 243 + 10 Nm
Engine mounting bolt M 10 45 Nm
Engine brace M 8 33 Nm
Screw adjusting ring spring preload shock abs.
M6 8 Nm
Spoke nipple M4,5 /M5 5 Nm
Other screws on chassis M 6 10 Nm
M 8 25 Nm
M 10 45 Nm
Other collar nuts on chassis M 6 15 Nm
M 8 30 Nm
M 10 50 Nm
T
IGHTENING TORQUES - CHASSIS
