TECHNICAL DATA 4
17
Screw, subframe bottom M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8x1 32 Nm (23.6 lbf ft)
Loctite
®
243™
Banjo bolt, brake line M10 24 Nm (17.7 lbf ft)
Nut, engine bearer, front M10 48 Nm (35.4 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 50 Nm (36.9 lbf ft)
Remaining screws, chassis M10 46 Nm (33.9 lbf ft)
Screw, side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Nut, side stand bracket M10x1.25 36 Nm (26.6 lbf ft)
Loctite
®
243™
Screw, bottom shock absorber M10x1.25 50 Nm (36.9 lbf ft)
Loctite
®
243™
Screw, front footrest bracket M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10x1.25 50 Nm (36.9 lbf ft)
Loctite
®
243™
Swingarm pivot M14 100 Nm (73.8 lbf ft)
Nut, rear wheel spindle M14x1.5 100 Nm (73.8 lbf ft)
Screw, steering head, top M16x1.5 47 Nm (34.7 lbf ft)
Loctite
®
243™
Lambda sensor M18x1.5 19 Nm (14 lbf ft)
Screw, subframe top M22 120 Nm (88.5 lbf ft)
Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft)
Nut, steering head M30x1 5 Nm (3.7 lbf ft)
Nut, steering head M30x1 Step 1
55 Nm (40.6 lbf ft)
2nd stage (loosen, counterclock-
wise)
2 turns
Step 3
5 Nm (3.7 lbf ft)
