R60723.0002–Index6c EN‐page45/62
(s)= staticswitching(levelevaluation)
INPUTCONFIGmustbesettoactiveLOW/HIGH

(d)= dynamicswitching(edgeevaluation)
INPUTCONFIGmustbesettoRISING/FALLINGEDGE
Continuation“CommandMenu”:

INPUT1CONFIG
Thisparameterdefinestheswitchingcharacteristicsoftheinput“Ctrl.In1”.

0 ACTIVELOW Activeat„LOW“(static)
1 ACTIVEHIGH Activeat„HIGH“(static)
2 RISINGEDGE Activateatrisingedge
3 FALLINGEDGE Activateatfallingedge

INPUT2ACTION
Thisparameterdefinesthefunctionoftheinput“Ctrl.In2”.
SeeparameterINPUT1ACTION.


INPUT2CONFIG
Thisparameterdefinestheswitchingcharacteristicsoftheinput“Ctrl.In2”.
SeeparameterINPUT1CONFIG.


INPUT3ACTION
Thisparameterdefinesthefunctionoftheinput“Ctrl.In3”.
SeeparameterINPUT1ACTION.

INPUT3CONFIG
Thisparameterdefinestheswitchingcharacteristicsoftheinput“Ctrl.In3”.
SeeparameterINPUT1CONFIG.


