Kubler 571T - Diagnostics

R60723.0002–Index6c EN‐page52/62
Accesstoactualdata
HoldingRegister0x1000/0x1001hexandfollowingallowaccesstovariablesofthedevice
(actualdataregisters):
HoldingRegister0x1000/0x1001hexActualdatawithserialCode“:0”(Display
value)
HoldingRegister0x1002/0x1003hexActualdatawithserialCode“:1”
Holding
Register0x1004/0x1005hexActualdatawithserialCode“:2”
HoldingRegister0x1006/0x1007hexActualdatawithserialCode“:3”
etc.
Accesstostatusregisters
HoldingRegister0x2000/0x2001hexandfollowingallowaccesstostatusregistersofthe
device:
oldingRegister0x2000/
0x2001hexOutputStatus(Ctrl.Outstatus,readonly)
HoldingRegister0x2002/0x2003hexSerialCommands
HoldingRegister0x2004/0x2005hexExternalCommand(Ctrl.Instatus,readonly)
HoldingRegister0x2006/0x2007hexAllCommands(readonly)
6.2.2.1 Read Coils and Write Single Coil
Withthefunctions“ReadCoils”and“WriteSingleCoil”itispossibletoreadandset/reset
singlecommands:

Coil
number
Serialcode
ofcommand
Command
0 54 Reset/Set Reset/SetValue
1 55 FreezeDisplay Freezeactualdisplayvalue
2 56 TouchDisable Disabletouchscreen
3 57 ClearLock Loosenlockingofalloutputs/relay
4 58 ClearMin/Max Resetofthemin./max.values
5 59 SerialPrint(donot
usewithModbus)
Sendingofserialdata
6 60 TeachPreset1 CurrentdisplayvalueisstoredasPRESELECTION1
7 61 TeachPreset2 CurrentdisplayvalueisstoredasPRESELECTION2
8 62 TeachPreset3 CurrentdisplayvalueisstoredasPRESELECTION3
9 63 TeachPreset4 CurrentdisplayvalueisstoredasPRESELECTION4
10 64 ScrollDisplay Displayswitching(seedisplayinoperationmode)
11 65 ClearLoopTime Releasealllatchedswitchingconditions
12 66 StartPreselection Thepreselectionstarts
13 67 ActivateData(not
requiredwith
Modbus)
Thedataisactivated.
14 68 StoretoEEPROM StoretoEEPROM
15 69 Testprogram(donot
usewithModbus)
Testprogram(donotusewithModbus)
6.2.3 Diagnostics
Thedevicesupportsthediagnosticssubfunction00“ReturnQueryData”.Other
diagnosticsfunctionsarenotavailable.

