R60723.0002–Index6c EN‐page53/62
6.3 Parameter/serialcodes
# Menue Name
Serial
Code
Min Max Default
0 GENERALMENU OPERATIONALMODE 0 0 4 0
1 GENERALMENU ENCODERPROPERTIES 1 0 3 0
2 GENERALMENU ENCODERSUPPLY 2 0 1 0
3 GENERALMENU COUNTINGDIRECTION 3 0 1 0
4 GENERALMENU SCALEUNITS 4 0 28 0
5 GENERALMENU SCALEUNITS(BATCH) 5 0 28 16
6 GENERALMENU LINIARIZATIONMODE 6 0 2 0
7 GENERALMENU PINPRESELECTION 7 0 9999 0
8 GENERALMENU PINPARAMETER 8 0 9999 0
9 GENERALMENU BACK‐UPMEMORY 9 0 1 1
10 GENERALMENU FACTORYSETTINGS 10 0 1 0
11 GENERALMENU‐ 11 0 0 0
12 MODESPEED DISPLAYVALUE 12 1 99999999 1000
13 MODESPEED BASEFREQUENCY(HZ) 13 1 500000 100
14 MODESPEED DECMIALPOINT 14 0 7 1
15 MODESPEED SAMPLINGTIME(S) 15 5 9999 100
16 MODESPEED WAITTIME(S) 16 1 8000 100
17 MODESPEED STANDSTILLTIME(S) 17 0 9999 0
18 MODESPEED AVERAGEFILTER 18 0 8 0
19 MODESPEED FOR/REVDETECTION 19 0 1 0
20 MODESPEED‐ 20 0 0 0
21 MODESPEED‐ 21 0 0 0
22 MODEPROCESSTIME DISPLAYFORMAT 22 0 3 0
23 MODEPROCESSTIME DISPLAYVALUE 23 1 99999999 1000
24 MODEPROCESSTIME BASEFREQUENCY(HZ) 24 1 500000 100
25 MODEPROCESSTIME SAMPLINGTIME(S) 25 5 9999 100
26 MODEPROCESSTIME WAITTIME(S) 26 1 8000 100
27 MODEPROCESSTIME STANDSTILLTIME(S) 27 0 9999 0
28 MODEPROCESSTIME AVERAGEFILTER 28 0 8 0
29 MODEPROCESSTIME‐ 29 0 0 0
30 MODEPROCESSTIME‐ 30 0 0 0
31 MODETIMER TIMEBASE 31 0 9 0
32 MODETIMER START/STOP 32 0 3 2
33 MODETIMER AUTORESET 33 0 1 0
34 MODETIMER LATCHFUNCTION 34 0 1 0
35 MODETIMER SETVALUE 35 0 99999999 0
36 MODETIMER INC/DECMODE 36 0 1 0
37 MODETIMER TOTALTIMEMODE 37 0 1 0
38 MODETIMER TOTALTIMESETVALUE 38 0 99999999 0
39 MODETIMER‐ 39 0 0 0
40 MODECOUNTER COUNTMODE 40 0 5 3
41 MODECOUNTER FACTOR 41 1 9999999 100000
42 MODECOUNTER SETVALUE 42‐99999999 99999999 0
43 MODECOUNTER DECIMALPOINT 43 0 7 0
44 MODECOUNTER BATCH/TOTALMODE 44 0 4 0
45 MODECOUNTER BATCH/TOTALSETVALUE 45 0 99999999 0
46 MODECOUNTER ROUNDLOOPVALUE 46 0 99999999 0
47 MODECOUNTER‐ 47 0 0 0
48 MODECOUNTER‐ 48 0 0 0
